PREPARATION
SuPPlIEd AccESSORIES
Note: A type code (K, E, or M4) can be found on the label attached to the package box.
Item Part Number Quantity
Microphone T9-0657-XX
Microphone hanger J9-584-XX
DC power cable
(with 20 A fuses)
K, M4 types E30-7628-XX
E type E30-3452-XX
Mounting bracket J29-0628-XX
Screw set N99-033-XX
Fuse (5 A)
K, M4 types F5-0079-XX
E type F52-0024-XX
Warranty Card K, E types only ——
Instruction manual B62-926-XX
MOBIlE INSTAllATION
Select a safe, convenient location inside your vehicle that will minimize danger to
your passengers and yourself while the vehicle is in motion. Consider installing
the transceiver under the dash in front of the passenger seat so that knees or legs
will not strike the radio during sudden braking of your vehicle. Try to a pick
well-ventilated location that is shielded from direct sunlight.
Note: You may experience interference on your GPS receiver when using in or around 438.8 MHz
(A band) and/or 443.8 MHz (B band). To eliminate the interference, ensure that the transceiver is
installed at a location separate from your GPS receiver.
1 Install the mounting bracket in the vehicle using the supplied self-tapping
screws and flat washers (4 of each are supplied).
• The bracket can be mounted with the bracket opening facing down, for underdash
mounting, or facing up.
• The bracket must be installed so that the 3 screw slots on the edge of each bracket
side are facing the back.
Self-tapping screw
(5 x 6 mm)
Flat washer
