SPECIFICATIONS
Specifications are subject to change without notice due to advancements in
technology.
General
TM-V71A TM-V71E TM-V71A
K Type E Type M4 Type
Guaranteed
range
Band
A & B
TX & RX
144 ~ 148 MHz 144 ~ 146 MHz
438 ~ 450 MHz 430 ~ 440 MHz
Frequency
range
Band A
RX
118 ~ 524 MHz —
Band B
136 ~ 524 MHz —
800 ~ 1300 MHz
(K type: excluding cellular band)
—
Mode F2D/ F3E
Antenna impedance 50 Ω
Operating temperature range –20°C ~ +60°C (–4°F ~ +140°F)
Power requirement 13.8 V DC ±15% (Negative ground)
Frequency stability Within ±5 ppm (–10°C ~ +50°C)
Current
TX
VHF
Hi Less than 13.0 A —
Mid Less than 5.5 A Less than 9.0 A
Low Less than 4.0 A
UHF
Hi Less than 13.0 A —
Mid Less than 6.5 A Less than 9.0 A
Low Less than 5.0 A
RX Less than 1.2 A (at 2W audio output)
Dimensions
(W x H x D)
Without projections
Panel: 140 x 43 x 38.2 mm (5.51" x 1.69" x 1.50")
Body (with Panel): 140 x 43 x 180.7 mm (5.51" x 1.69" x 7.11")
With projections
Panel: 140 x 43 x 55.4 mm (5.51" x 1.69" x 2.18")
Body (with Panel): 140 x 43 x 213.1 mm (5.51" x 1.69" x 8.39")
Weight (approx.) Body (with Panel): 1.5 kg (3.3 lbs)
Concerning the received frequency display, an unmodulated signal may be received. This is
according to the set intrinsic frequency form.
VxU reception
(144 MHz + 45.05 MHz) x 2 – (430 MHz - 49.95 MHz) = 45.05 MHz, 49.95 MHz
(144 MHz + 45.05 MHz) x 4 – (430 MHz - 49.95 MHz) x 2 = 45.05 MHz, 49.95 MHz
UxV reception
(430 MHz - 45.05 MHz) – (144 MHz + 49.95 MHz) x 2 = 45.05 MHz, 49.95 MHz
(430 MHz - 45.05 MHz) x 2 – (144 MHz + 49.95 MHz) x 4 = 45.05 MHz, 49.95 MHz
