7
AccESSORy cONNEcTIONS
n
External Speakers
If you plan to use external speakers, choose speakers with an impedance of
8 Ω. The external speaker jacks accept a 3.5 mm (1/8”) mono (2-conductor)
plug. We recommend using SP-50B speakers.
There are 2 speaker jacks on the rear of the transceiver: SP 1 and SP 2.
Refer to page 7 to determine how the speakers will be used.
n
Microphone
To communicate using voice, connect the supplied microphone to the MIC jack
on the left side of the transceiver. Press firmly on the plug until the locking tab
clicks.
SP 1 jack
SP 2 jack
External speakers (SP-50B)
Microphone
connector
MIC jack
• Attach the microphone hanger to an appropriate position using the screws included
in the screw set.
Microphone hanger
Screw (3 x 0 mm)
