GETTING ACQUAINTED
① Selector knob
Rotate to select a zone or channel.
② Power switch/ Volume control
Rotate to turn the transceiver ON/OFF and to adjust the
volume.
③ Auxiliary key
Press to activate its programmable function {page 7}.
④ Transmit/ Receive/ Battery low indicator
If enabled by your dealer, lights red while transmitting,
green while receiving a call, and orange when receiving an
optional signaling call (2-tone, DTMF signaling, etc.). Blinks
red when the battery power is low while transmitting.
⑤ PTT (Push-To-Talk) switch
Press and hold this switch, then speak into the microphone
to call a station.
1
2 ABC
5 JKL
0
8 TUV
4
7
GHI
PQRS
3 DEF
6 MNO
MIC
#
9 WXYZ
