2
PREPARATION
i
nStAlling
/ r
emoving the
(o
ptionAl
) B
Attery
p
Ack
1 Match the guides of the
battery pack with the grooves
on the upper rear of the
transceiver, then firmly press
the battery pack in place.
2 Lock the safety catch to
prevent accidentally releasing
the battery pack.
3 To remove the battery pack,
lift the safety catch, press the
release latch, then pull the
battery pack away from the
transceiver.
Note:
◆
For battery pack charging procedures and useage, refer to the
battery charger Instruction Manual.
◆
Before charging a battery pack that is attached to the
transceiver, ensure that the safety catch is firmly closed.
i
nStAlling the
(o
ptionAl
) A
ntennA
Screw the antenna into the
connector on the top of the
transceiver by holding the
antenna at its base and turning
it clockwise until secure.
1
2
3
1
2AB C
4 GH I 3 DEF
MI C
Optional
antenna
