Kenwood ProTalkXLS TK-3230 - Manual (Page 19)

0
i
nStAlling
/ r
emoving
o
ptionAl
A
cceSSorieS
Note: Always switch OFF the transceiver power when installing or
removing optional accessories.
The following accessories can be used with this transceiver:
• KMC-17 Speaker-Microphone
• KMC-21 Speaker-Microphone
• KHS-22 Headset
• EMC-3 Clip Microphone with Earphone
• KBH-14 Belt clip
To install these accessories:
Open the SP/MIC tabs on the side of the transceiver.
Insert the accessory’s plugs into the
SP/MIC jacks.
When you remove the accessory
from the transceiver, be sure to cover
the SP/MIC jacks with the attached
tabs, in order to keep dust and dirt
away from the contacts.
Note: Refer to the accessory instruction manuals for detailed
instructions on each of these accessories.
