A - 2 DS6707 Digital Imager Scanner Product Reference Guide
Transmit “No Read” Message 5Eh Disable 4-17
Imaging Preferences
Decoding Options
Operational Modes N/A N/A 5-4
Image Capture Autoexposure F0h 68h Enable 5-5
Image Capture Illumination F0h 69h Enable 5-6
Fixed Exposure F4h F1h 37h 100 5-6
Fixed Gain F1h 38h 50 5-7
Gain Exposure Priority for Snapshot Mode F1h 32h Autodetect 5-7
Snapshot Mode Timeout F0h 43h 0 (30 seconds) 5-8
Snapshot Aiming Pattern F0h 2Ch Enable 5-9
Image Cropping F0h 2Dh Disable 5-9
Crop to Pixel Addresses F4h F0h 3Bh;
F4h F0h 3Ch;
F4h F0h 3Dh;
F4h F0h 3Eh 0 top, 0 left, 1023 bottom, 1279
right 5-10
Image Size (Number of Pixels) F0h 2Eh Full 5-11
Image Brightness (Target White) F0h 86h 180 5-12
JPEG Image Options F0h 2Bh Quality 5-12
JPEG Target File Size F1h 31h 160 kB 5-13
JPEG Quality and Size Value F0h 31h 65 5-13
Image Enhancement F1h 34h Off (0) 5-14
Image File Format Selection F0h 30h JPEG 5-15
Bits per Pixel (BPP) F0h 2Fh 8 BPP 5-16
Signature Capture 5Dh Disable 5-17
Signature Capture Image File Format
Selection F0h 39h JPEG 5-18
Signature Capture Bits per Pixel (BPP) F0h 3Ah 8 BPP 5-19
Signature Capture Width F4h F0h 6Eh 400 5-20
Signature Capture Height F4h F0h 6Fh 100 5-20
Table A-1 Standard Default Parameters Table (Continued)
Parameter
Parameter
Number
Default
Page
Number
1
User selection is required to configure this interface and this is the most common selection.
