Operating the Panel PC 670/870 Release 11/02
3–10 SIMATIC Panel PC 670/870 Start-Up Instructions
3.3.3 Keypad
Call in
Select one of the following files according to the keypad front:
Keypad front File
10" c:\drivers.xxx\keypad\keypads10.exe
12" c:\drivers.xxx\keypad\keypads12.exe
15"
c:\drivers.xxx\keypad\keypads15.exe
"xxx" has the following significance:
• Windows 98:
w98
• Windows NT:
nt4
• Windows 2000:
w2k
• Windows XP:
wxp
Function
Applies for Windows 98, Windows 2000 and Windows XP:
The Keypad tool can be used to modify the predefined keyboard assignment
on the membrane keyboard.
Figure 3–5 Keypad
