Release 11/02 Operating the Panel PC 670/870
SIMATIC Panel PC 670/870 Start-Up Instructions 3–3
Notice
Check whether the active Partition C still exists. Use the MS-DOS tool fdisk, for
example, to do this. If the active partition is no longer available, recreate it,
observing the following:
If the active Partition C is no longer available and the EasyRestore program is
started, data is lost on Partition D.
Observe the following procedures during the restore process to reset the initial
state of drive C.
Windows NT, Windows 98
• Call in the BIOS, select the settings Main → Boot Options and check that
menu item Boot Sequence. The menu item must be set so that it is possible
to boot from the CD-ROM.
• Insert the Restore-CD and restart the Panel PC anew.
• Affirm the license agreement and read the warning message.
After confirmation, the original image is restored on drive C.
Windows 2000, Windows XP
• Call in the BIOS, select the settings Main → Boot Options and check that
menu item Boot Sequence. The menu item must be set so that it is possible
to boot from disk.
• Insert the Restore disk and Restore CD 1 and restart the Panel PC anew.
• Insert Restore-CD 2 following the corresponding request.
Affirm the license agreement and read the warning message.
After confirmation, the original image is restored on drive C. Follow the
instructions which appear on the screen.
Recovery CD
Note
The Recovery-CD can be used for the installation or restoring the operating
system. Only those drivers required for that specific operating system are
installed.
The drivers required by the Panel PC 670/870 are contained on the
Panel PC 670/870 Documentation & Drivers CD. A setup is necessary in order
to install the drivers. This is on the CD under:
InstallshieldPC670_870\setup.exe
