e-Keying as described in the AMC.0 specification

■

FRU information

■

LED indicators for hot-swap and OOS (out of service)

2.2.6

Port Connectors

The AMC includes connectors to communicate with the host board and take its
interfaces outside the ATCA chassis. Refer to

for complete connector

descriptions and pin-outs.

2.2.7

LEDs

The AMC.1-HDD SAS disk has three LEDs. See the next section for a detailed
description of the LEDs.

2.3

Faceplate and LEDs

The faceplate of the AMC.1-HDD SAS disk has three LED indicators, which are
described in the table following the faceplate illustration.

Note –

The AMC is available in different capacities (in gigabytes). The illustration

shows a generic faceplate. For your product’s faceplate, the xxx denotes the capacity.

FIGURE 2-2

Faceplate
