1-14 Sun Netra CP3000 Advanced Mezzanine Card PCIe Hard Drive and SAS Controller User’s Guide • March 2010
3. Obtain the AMC card from the ship kit.
Note – Be sure to follow unpacking and handling instructions. See Section 1.2,
“Unpacking” on page 1-3 and Section 1.3, “Handling AMCs” on page 1-4 .
FIGURE 1-5 Sample Top View
Note – The illustration shows a sample of the top view for a 146GB AMC. If your
AMC has a different capacity, the label shows it.
4. Perform any card-specific hardware procedures, if necessary.
5. Prepare the AMC by fully opening its injector/ejector latches to the OUT
position.
