Simrad EQ60
62
857-164342 / Rev.C
Install menu
The following commands are available on the Install menu:
→ Transceiver, page 112
→ Environment, page 85
→ Navigation, page 95
→ Trawl, page 116
→ Purse Seine, page 104
→ Heave, page 88
→ Temperature, page 111
→ BI500, page 73
Transceiver
This command opens the
Transceiver Installation
dialogue box.
Use this to install a new transceiver, and to assign a transducer
to each frequency channel.
Environment
Select this command to open the
Environment
dialogue box.
The settings here are used to select salt or fresh water
absorption, and to enter the sound velocity value.
Navigation
This command opens the
Navigation Interface
dialogue box. In
this box, you can select communication parameters for the
NMEA interface, and select input/output telegrams.
Trawl
This command option opens the
Trawl Interface
dialogue box.
Use these parameters to select trawl instrumentation
communication parameters; input/output telegrams.
Purse seine
This command option opens the
Purse Seine
dialogue box. Use
these parameters to select trawl instrumentation communication
parameters; input/output telegrams.
Heave
This command opens the
Heave Sensor
dialogue box. It is used
to select heave input source; analogue or RS-232.
Temperature
This command option opens the
Temperature Sensor
dialogue
box.
BI500
This command option opens the
BI500
dialogue box.
