Simrad EQ60
144
857-164342 / Rev.C
Standard AC power cable
This cable is a standard three-wire power cable. It is
commercially available in standard lengths, or may be produced
locally to suit the specific installation needs. The instrument end
is terminated in a standard IEC female socket, while the other
end is terminated in a plug suitable for the local standard.
W301 / Rev B Standard power cable for 115/230 Vac 2-phase
Live (normally Blue)
Neutral (normally Brown)
Use the applicable plug to suit
local standard. British standard
plug used as example only.
Ground (always Yellow or Yellow/Green)
IEC plug
Note
Different cable colours may be used for the “live” and
“neutral” wires. Ground is however always on green/yellow.
Conductors 2 x 1.5 mm 2 + GND
Screen None
Voltage 750 V
Max. diameter Set by the plugs
