Getting started
31
857-164342 / Rev.C
Navigation interface
To link acoustical data with navigational data the EQ60 must be
able to receive data provided by a GPS or another positioning
system. The Navigation Interface dialogue box is used to
define the parameters to achieve this.
Open the Install menu, choose the Navigation command to
open the Navigation Interface dialogue box.
Specify how the EQ60 will receive navigational data. Since the
NMEA standard has been implemented, you only need to
choose between NMEA or ASCII.
Click OK when you have made the setting.
Additional interfaces
Additional interfaces have been provided for other peripheral
systems.
• If you need to link recorded acoustical data with trawl
position data, choose the Trawl command on the Install
menu to specify the trawl position interface.
• If you need to connect your EQ60 to a purse seine system,
choose the Purse seine command on the Install menu to
specify the purse seine system interface.
If you want to use a heave or a temperature sensor, choose the
Heave and Temperature commands on the Install menu to
specify these interfaces.
Related topics
→
Power on/off procedure, page 39
→ Display views, introduction, page 15
→ Frequency channels installation procedure, page 45
→ Transceiver Installation, page 112
→ Transceiver Settings, page 114
→ Environment, page 85
→ Navigation Interface, page 95
→ Heave Sensor, page 88
→ Temperature Sensor, page 111
→ Trawl Interface, page 116
→ Purse Seine, page 104
