Simrad EQ60
12
857-164342 / Rev.C
External interfaces
Numerous external interfaces are provided for the EQ60 echo
sounder system.
Outputs
• Echogram printer (Centronics parallel)
• Bottom depth (NMEA)
• Depth data (NMEA, Simrad or Atlas)
Inputs
• Navigation receiver (NMEA)
• Motion sensor (Heave, roll and pitch)
• Analogue heave, roll and pitch (+/- 10 V)
• Annotation
• Transmit synchronization
• Temperature sensor
Remote control toggle switches
• Survey Line
• Remote power
• Transmit synchronization
