Simrad EQ60
50
857-164342 / Rev.C
1 Select Operation on the
File
menu.
- Observe the
Operation
dialogue box appear.
2 Click Save in the History field.
3 Click Browse to select disk directory.
4 Click Ok to start the recording.
To stop History recording:
1 Select Operation on the File menu.
- Observe the Operation dialogue box appear.
2 De-select Save.
3 Click Ok.
Playback
To view the information recorded by the History function:
1 Select History on the
View
menu.
2 Browse the information in the
History
dialogue box.
The information provided by the History view is presented in a
separate window. The echo sounder will operate normally in the
background. However, you will not have access to any of the
menues as long as the History window is open. When you wish
to focus on the echo sounder operation, close or minimize the
History window.
Print the current History information
To print the current view in the History window:
1 Select History on the View menu.
2 Press the printer symbol in the bottom right corner to print
a single history file.
- Note that only the file presented on the display is
printed.
(C
D
5
639
A
)
A
B
(A) Press to print current view
( B) Press to print multiple views
