Simrad EQ60 - Manual (Page 66)

Simrad EQ60
54
857-164342 / Rev.C
1 Open the Control Panel to access the Network
connections.
2 Open the Local area connection.
3 Press Properties.
- Observe the Local Area Connection Properties
dialogue box appear.
4 Select the General tab, and click on Internet Protocol
(TCP/IP)
5 Press Properties.
- Observe the Internet Protocol (TCP/IP) Properties
dialogue box appear.
6 Click Use the following IP address, and enter the
following IP address: 157.237.14.12
- The Subnet mask will automatically be set to
255.255.0.0.
7 Click OK to accept the choice and to close the Internet
Protocol (TCP/IP) Properties dialogue box.
8 Click OK in the remaining dialogue boxes until all are
closed.
9 Restart the computer.
How to obtain a licence number
Each individual computer used to run EQ60 software will
require a dedicated licence code. When a third party computer is
used, this code must be obtained from the manufacturer.
Observe the following procedure:
1 Observe the My computer icon on the computer desktop.
2 Right-click once on the icon, then left-click to open the
short-cut menu.
3 Select Properties.
4 Select the General tab.
5 Observe the information provided under Registered to:
6 Write down the number provided
7 Press Cancel to close the dialogue box.
8 Send the registration number and the serial number on
your GPT(s) to your local dealer to obtain a licence code.
