Heave and Temperature sensors
This cable is used to connect the General Purpose Transceiver
(GPT) to external Heave and Temperature sensors.
W620c / Rev C Heave, Roll, Pitch and Temperature sensors
17
GPT 25-pin D-sub connector
4
2
1
Pitch(+)
Temp(+)
Roll(+)
Temp(AGND)
SIMRAD GPT
25
14
1
13
Auxiliary
connector
(female)
The cable screen is connected
to the plug house.
Heave(+)
Pitch(-)
Roll(-)
Heave(-)
3
14
15
16
Conductors 2 x 0.22 mm2
Screen Overall braided
Voltage 60 V
Max.diameter Set by the plugs
