42
M412616
Screw four leveling legs back into level adjusting
fittings from top. Slide tumbler to its permanent
location and level. Keep tumbler as close to floor as
possible. All four legs must rest firmly on floor so
weight of tumbler is evenly distributed. Tumbler must
not rock. Tumbler may be removed from skid before moving to
installation location or moved while still attached to
skid. Remove tumbler from skid by unscrewing four
shipping capscrews (one at each corner) and remove
tumbler from skid. Lint panel door will have to be
removed in order to remove two front capscrews.
Each tumbler should be leveled within
¹⁄₈
inch
(3.2 mm) from front to rear, and ¹⁄₈ inch (3.2 mm) from
side to side. Check front to rear level by rotating
clothes cylinder until one rib is at bottom, then place a
GAS REQUIREMENTS (Gas Drying Tumblers)
ࡽ
To reduce the risk of fire or explosion,
if the tumbler is to be connected to
Liquefied Petroleum (L.P.) gas, a vent
to the outdoors must be provided in
the room where the tumbler is
installed.
Size of gas service pipe is dependent upon many
variables (lengths, tees, etc.). Specific pipe size
information should be obtained from gas supplier.
Refer to table in
Figure 22 for general pipe size data.
It is important that equal gas pressure be maintained
at all tumbler gas connections. This can best be done
by installing a one inch pipe gas loop as shown in
Figures 20 and 21.
WARNING
POSITIONING DRYING TUMBLER
NOTE: Do not throw these four capscrews away
— they are the leveling legs.
LEVELING DRYING TUMBLER
level on bottom rib. Side to side level should be
checked by placing a level on front and rear of top
panel.
