Speed Queen Drying Tumblers SCB50EG User Manual
Page 38
36
M412616
ELECTRICAL REQUIREMENTS
For 30 Pound (13 kg) Tumblers
REQUIREMENTS
Heat Source
Electrical Specs
Wires Required and Terminal Block Connection
Gas & Steam
230/50/1
L1
L2
Ground to PE Busbar
Electric
230/50/1
L1
L2
Ground to PE Busbar
Electric
380/50/3
L1
L2
L3
Ground to PE Busbar
Electric
415/50/3
L1
L2
L3
Ground to PE Busbar
Steam
380/50/3
L1
L2
L3
Ground to PE Busbar
Figure 7
ELECTRIC DRYING TUMBLERS
NOTE: DO NOT use aluminum wire.
ELECTRIC DRYING TUMBLERS
240 V, 1 Ph, 50 Hz.
240 V, 3 Ph, 50 Hz.
380 V, 3 Ph, 50 Hz.
415 V, 3 Ph, 50 Hz.
Minimum Wire Size
2 AWG (33.63 mm²) 6 AWG (13.32 mm²) 8 AWG (8.366 mm²) 8 AWG (8.366 mm²)
AMP Rating
90 Amp
54 Amp
33 Amp
30 Amp
Circuit Breaker
100 Amp
60 Amp
40 Amp
35 Amp
Poles
2
3
3
3
Figure 9
Figure 8
GAS AND HIGH PRESSURE STEAM DRYING TUMBLERS
GAS AND HIGH PRESSURE STEAM DRYING TUMBLERS
240 V, 1 Phase, 50 Hz.
380 V, 3 Phase, 50 Hz.
Minimum Wire Size
14 AWG (2.081 mm²)
14 AWG (2.081 mm²)
Circuit Breaker
15 AMP
15 AMP
Poles
2
2
