16
M412616
50 Pound (22 kg) Gas Tumblers
Cabinet Finish: Electrostatically applied thermosetting polyester
Cylinder: 37" x 30" (94 cm x 76.2 cm) perforated galvanized steel with four baffles;
50 pounds (22.7 kg) dry weight (cotton load)
Motor: 1/2 H.P., lifetime lubricated, internal overload protected
(Nonreversing Models) (See below for reversing models.)
Electrical Requirements: 230 Volt, 50 Hertz, 1 Phase, 6.0 Amp
Non-Reversing Models
Electrical Requirements: 230 Volt, 50 Hertz, 1 Phase, 8.0 Amp
Reversing Models
Gas Consumption: Energy Saver Models — 95,000 BTU per hour (100.2 MJ/hr.)
Standard Models — 120,000 BTU per hour (126.6 MJ/hr.)
Types of Gas: Factory equipped with Natural/Mixed Gas
(6-1/2
±
1-1/2 inch water column line pressure) (1.62
±
.37 kPa); or
Liquefied Petroleum gas (11
±
.3" water column line pressure)
(2.74
±
.07 kPa)
Gas Connection: 1/2 inch (12.7 mm) N.P.T.
Air Flow: Energy Saver Models — 390 C.F.M. at 0.5" W.C. (185 liters/sec. at 1.25 mBar)
Standard Models — 600 C.F.M. at 0.5" W.C. (284 liters/sec. at 1.25 mBar)
Net Weight: 545 Pounds (247 kg) (approximate)
Calorific Value: Natural Gas — 8900 kCal/m 3 (37.2 MJ/m 3 )
L.P. Gas — 22,250 kCal/m 3 (93.1 MJ/m 3 )
REVERSING MOTOR SIZES
GAS ELECTRIC
STEAM
HIGH PRESSURE LOW PRESSURE
50 LB.
FAN 1/3 H.P. 1/3 H.P. 1/3 H.P. 1/2 H.P.
CYLINDER 1/3 H.P. 1/3 H.P. 1/3 H.P. 1/3 H.P.
