beacon interval of 200 ms. The third has a signal strength of –56 dBm, is configured
on channel 11 with a beacon interval of 100 ms.
a b 7 b c 8
- 2 8
0 2
1 0 0
2 a e 5 7 8
- 4 8
0 6
2 0 0
2 a e 5 9 6
- 5 6
1 1 1 0 0
A n y
D e t l
When the any ESSID mode is selected, the summary display contains the first six
characters of the AP’s ESSID instead of the beacon interval as in the example below.
a b 7 b
- 2 8
0 2
A L P H A
2 a e 5
- 4 8
0 6
W S M T E S
2 a e 5
- 5 6
1 1
v o i c e
M y I D
D e t l
In detail mode the display would appear as follows. The left/right arrow keys will
move between AP indices.
i : b b b b b b
s n
c h
b c n
e e e e e e e e e e e
D G H I
r r r r r r r r r r r r r + x x x x
m m m
G : g g g g
P : p p p p
A n y
S m r y
Where:
• i = index of selected AP (value will be from 0 to 3 inclusive)
• bbbbbb = the last three octets of the BSSID for a discovered AP
• sn = signal strength in –dBm
• ch = channel
• bcn = beacon interval
• eeeeeeeeeee = SSID (up to first 11 characters)
• DGHI = standards supported
• rrrrrrrr = rates supported. Basic rates will have a “b” following the rate
• + – more rates are supported than those displayed
• xxxx = WMM or UPSD if those QoS methods are supported
• mmm = security mode
• G:gggg = group key security
• P:pppp = pairwise key security
• Any/MyID = softkey to toggle between “single SSID” and “any SSID” modes
• Detl/Smry = softkey to toggle between the multiple AP display (summary), and
the single AP display (detail)
