SpectraLink h340 - Manual (Page 26)

SpectraLink Corporation Configuration and Administration—NetLink e340/h340/i640 Wireless Telephone
with SIP
PN: 72-1089-02-D.doc Page 26
Ring Cadence The Ring Cadence is the rhythm of the ring. It may be set to a pre-
programmed ring cadence, or it may be set to obtain its cadence from the proxy
server. The PBX option is designed to utilize any distinctive rings sent by the proxy
server while allowing the user to set unique rings for auxiliary applications.
Off
PBX
Continuous
Short Pulse
Long Pulse
OK Up
Off : Silent
PBX : Proxy server determines ring cadence (e.g. the proxy server may send rings
that differentiate between internal and external calls)
Continuous : Rings continually until answered
Short Pulse : Rings in short bursts
Long Pulse : Rings in long bursts
Ring Tone Select from five available tones (scroll to Tone 5 option). The Play
softkey allows the user to preview the tone before selecting. If Ring Cadence is
turned off, the Ring Tone option will not appear on the menu.
Tone 1
Tone 2
Tone 3
Tone 4
Tone 5
OK Play Up
Ring Volume NetLink i640 Wireless Telephone only. The user may select a volume
level by pressing the Up and Down side buttons and then pressing the OK softkey.
The graduated volume bar indicates the levels. This setting may be overridden by
adjusting volume while the handset is ringing.
Vibrate Cadence Vibrate Cadence options are the same as for Ring Cadence (see
above).
Ring Delay Ring Delay determines how long the vibrate cadence will play before the
audible ring starts. If Ring Cadence and Vibrate Cadence are turned off, the Ring
Delay option will not appear on the menu.
No Delay
5 Second Delay
10 Second Delay
OK UP
