Completing the VoIP settings
If you have made all the required entries,
the message "
Connection data complete
" will
appear on the display. The handset returns
to idle status.
If all the settings are correct and if the
phone can establish a connection to the
VoIP server, then the internal name of the
handset will be displayed (example):
You can now use your phone to make calls
via the fixed network and the Internet.
Callers can reach you on your fixed
network number and your VoIP number.
No connection to the Internet/VoIP server
If one of the following messages is dis-
played instead of the internal name after
the connection assistant is closed, errors
have occurred:
u
Server not accessible!
u
Provider registration failed!
Below you will find possible causes and
measures you can take.
Server not accessible!
The phone has no connection to the Inter-
net.
¤
Check the cable connection between
the base station and the router (the
LED on the base station must light up)
and the connection between the router
and the Internet connection.
¤
Check whether the phone is connected
to the LAN.
– It may not have been possible to
dynamically assign an IP address to
the phone
or
– You have assigned a static IP address
to the phone that has either already
been assigned to another LAN sub-
scriber or does not belong to the
router's address block.
¤
Find the IP address using the hand-
set menu:
v
¢
Ð
¢
¢
Local Network
¤
Start the Web configurator with the
IP address.
¤
If no connection can be established,
change the settings on the router
(activate DHCP server) or the
phone's IP address.
Provider registration failed!
u
Your personal data for registering with
the VoIP provider may have been
entered incompletely or incorrectly.
¤
Check your entries for
Username
,
Authent. Name
and
Authent. Password
.
In particular, check your use of
upper and lower case.
To do this, open the following menu
on your handset:
v
¢
Ð
Settings
¢
Telephony
¢
VoIP
¢
Provider Registr.
If the attempt to create the entry fails
(e.g. because the phone is not connected
to the Internet), a message to this effect is
displayed briefly (see page 14). You can then
create the entry later via the Gigaset.net direc-
tory (see page 27).
Please note:
To ensure that you can always be reached via
the Internet, the router must be permanently
connected to the Internet.
Ð
V
INT 1
10.08.06
09:45
FixedLine
IP
