2-9 SATA and Floppy Drive Connections
Note the following conditions when connecting the Serial ATA and floppy disk drive
cables:
• Be sure to use the correct cable for each connector. Refer to Page 1-1 for cables
that came with your shipment.
• A red mark on a wire indicates the location of pin 1.
A
SATA Connections
Six Serial ATA (SATA) connectors (I-SATA
0~5) are located on the X8SIL-F motherboard
(4 SATA ports for the X8SIL). These Serial
Link connections provide faster data transmis-
sion than legacy Parallel ATA. See the table
on the right for pin definitions.
SATA/SAS Connectors
Pin Definitions
Pin# Signal
1
Ground
2
SATA_TXP
3
SATA_TXN
4
Ground
5
SATA_RXN
6
SATA_RXP
7
Ground
B
A. I-SATA 0
B. I-SATA 1
C. I-SATA 2
D. I-SATA 3
E. I-SATA 4
F. I-SATA 5
