1. Backplane USB 0
2. Backplane USB 1
3. Front Panel USB 10/11
4. Front Panel USB 2/3 (X8SIL-F Only)
5. Internal 'Type A' USB 4
Universal Serial Bus (USB)
Two Universal Serial Bus ports (USB
0/1) are located on the I/O back panel.
Additional four USB connections, USB
2/3 (X8SIL-F) and USB 10/11 are used
to provide front chassis access. USB 4
is a Type A Connector. (USB Cables
are not included). See the tables on
the right for pin definitions.
Back Panel USB 0/1
Pin Definitions
Pin# Definition Pin# Definition
1 +5V 5 +5V
2 USB_PN1 6 USB_PN0
3 USB_PP1 7 USB_PP0
4 Ground 8 Ground
Front Panel USB 2/3, 10/11
Pin Definitions
USB 2, 3
Pin # Definition
USB 10/11
Pin # Definition
1 +5V 6 +5V
2 USB_PN2 7 USB_PN3
3 USB_PP2 8 USB_PP3
4 Ground 9 Ground
5 No Con-
nection
10 Key
4 3 5
