Chapter 2 StorEdge A3500 Configurations 2-27
The power connections for the 1x8 cabinet are shown in FIGURE 2-25 .
FIGURE 2-25 One A3000 Controller Modules and Eight D1000 Disk Arrays (Power)
R1&R2 R8
R6 R4 R9 R3
R5 R7
Front
sequencer
L1&L2 L8
L6 L4 L9 L3
L5 L7
Rear
sequencer
L1
L2
L3
L6
L7
L8
L9
L4
R1
R2
R3
R6
R7
R8
R9
R4
L5
R5
Rear view
