2-26 Sun StorEdge A3500 Hardware Configuration Guide • September 1998
FIGURE 2-23 Power Connections to Avoid (Different Phases)
FIGURE 2-24 Power Connections to Avoid (Same Phase)
2.5.4 Power Connections
The power connections for 2x7 cabinet are the same as those in the standard 2x7
expansion cabinet (
FIGURE 2-18 ).
2x7
Phase A
1x8
Phase B
2x7 1x8
Same phase AC
