2-2 Sun StorEdge A3500 Hardware Configuration Guide • September 1998
2.1 StorEdge D1000 Disk Array Settings
This section describes how to set the following attributes for StorEdge D1000
disk arrays (
FIGURE 2-1 ) in 1x2, 1x5, 2x7, and 3x15 configurations:
■ Option switch
■ Module ID
■ SCSI jumper cables and terminators
FIGURE 2-1 StorEdge D1000 Disk Array
IN/OUT-1 IN/OUT-1 IN/OUT -2 IN/OUT -2
Option Switch
Module ID
Rear
