42 XLi IEEE 1588 Clock
997-01510-03, Rev. C, 12/12/2006
S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S
1
For example, to display the date and time, send:
F3
XLi responds:
F3 UTC 01/01/2002 00:05:34
To set the time and date, send:
F3 UTC 07/14/2002 18:20:30
Only valid times and dates are accepted. The XLi responds:
OK
F4 – Serial Port Configuration
Use function F4 to change or display the serial port settings. The factory settings are:
• Interface – RS-232
• Baud rate – 9600
• Data bits – 8
• Parity – NONE (only available/valid when Data Bits is set to 8)
• Stop bits – 1
Command Line
To display the Serial Port settings, send:
F4
XLi responds:
F4
= two-digit seconds.
= carriage return character.
= line feed character.
