Chapter 4: BIOS

4-7

Serial 2 Address

This option specifi es the base I/O port address and Interrupt Request address

of serial port 2. Select "Disabled" to prevent the serial port from accessing any

system resources. When this option is set to "Disabled", the serial port physically

becomes unavailable. Select "2F8/IRQ3" to allow the serial port to use 2F8 as its

I/O port address and IRQ 3 for the interrupt address. Options include Disabled,

2F8/IRQ3, 3E8/IRQ4 and 2F8/IRQ3.

Serial Port Mode

This sets the serial port mode for your system. Options include Normal, IrDA

and ASK IR.

Restore on AC Power Loss

This sets the action that occurs when an AC power loss occurs. Options include

Power Off, Power On and Last State.

Watch Dog Timer

This sets the Watch Dog Timer. Options include Enabled or Disabled.

Hyper-Transport Confi guration

NODE0: PCI-X2 HT Link

Link Speed

The Hyper Transport link will run at this speed if it is slower than or equal

to the system clock speed. Options include 1 GHz and Auto.

Link Width

Hyper Transport runs at this width. Options include Auto, 4 Bit, 8 Bit and

16 Bit.

NODE0: NODE1 HT Link Speed

Link Speed

The Hyper Transport link will run at this speed if it is slower than or equal

to the system clock speed and what the board is capable. Options include

1 GHz and Auto.
