Chapter 2: Installation

2-19

SATA Ports

There are no jumpers to confi gure the SATA

ports, which are designated SATA0 through

SATA5. See the table on the right for pin

defi nitions.

SATA Ports

Pin Defi nitions

(SATA0-SATA3)

Pin # Defi nition

1

Ground

2

TXP

3

TXN

4

Ground

5

RXN

6

RXP

7

Ground

SAS Ports

Pin Defi nitions
(SAS0 ~ SAS7)

Pin# Defi nition Pin # Defi nition

1

Ground

2

TXP

3

TXN

4

Ground

5

RXN

6

RXP

7

Ground

SAS Ports (H8QI6-F Only)

There are eight SAS ports included on the

motherboard. See the table on the right for

pin defi nitions.

Note: JPS1 must be set correctly to enable

the SAS controller.
