H8QI6/i-F Serverboard User's Manual
2-10
Universal Serial Bus Ports
Two Universal Serial Bus ports (USB 2.0) are
located beside the Keyboard and Mouse PS2
ports. Two additional Type A ports (USB4/5)
are included on the motherboard. See the
table on the right for pin defi nitions.
Universal Serial Bus Ports
Pin Defi nitions (USB0/1, USB4/5)
USB0
Pin # Defi nition USB1
Pin # Defi nition
1 +5V 1 +5V
2 PO- 2 PO-
3 PO+ 3 PO+
4 Ground 4 Ground
USB Headers
Four USB 2.0 headers (USB2/3 and USB6/7)
are also included on the motherboard. These
may be connected to provide front side ac-
cess. A USB cable (not included) is needed
for the connection. See the table on the right
for pin defi nitions.
Universal Serial Bus Headers
Pin Defi nitions (USB2/3, USB6/7)
USB2
Pin # Defi nition USB3
Pin # Defi nition
1 +5V 1 +5V
2 PO- 2 PO-
3 PO+ 3 PO+
4 Ground 4 Ground
5 Key 5 NC
Fan Header
Pin Defi nitions
Pin# Defi nition
1 Ground
2 +12V
3 Tachometer
4 PWR Modulation
Fan Headers
This motherboard has eight fan headers
(Fan1 to Fan9). These 4-pin fans headers
are backward compatible with 3-pin fans.
However, fan speed control is available for
4-pin fans only. The fan speeds are con-
trolled by the BIOS. See the table on the right
for pin defi nitions
Note: NC indicates no connection.
Serial Ports
The COM1 serial port is located beside the
VGA port. Refer to the motherboard layout
for the location of the COM2 header. See the
table on the right for pin defi nitions.
Note: NC indicates no connection.
Serial Port Pin Defi nitions
(COM1/COM2)
Pin # Defi nition Pin # Defi nition
1 DCD 6 DSR
2 RXD 7 RTS
3 TXD 8 CTS
4 DTR 9 RI
5 Ground 10 NC
