A-2
S UPER S ERVER 6113L-8/6113L-i User's Manual
A-2 IA-64 Common Debug Codes
DS4 DS3
On On: SNC found and start memory sizing
On Off: Initial system memory and SIOH
Off On: Valid memory and SIOH found
Off Off: ICH4 found
Common Debug Codes for IA-64 systems are listed below:
Checkpoints Code Description
Note: The debug code LEDs (DS3 and DS4) are located next to the IDE2 connector.
Please refer to the serverboard layout in Chapter 5 for DS3 and DS4 locations.
