S UPER S ERVER 6113L-8/6113L-i User's Manual
3-2
3-3 Control Panel LEDs
The control panel located on the front of th SC813HS-500/SC813Hi-500 chassis
has four LEDs. These LEDs provide you with critical information related to
different parts of the system. This section explains what each LED indicates
when illuminated and any corrective action you may need to take.
! OVERHEAT: Indicates an overheat condition in the chassis. This may be
caused by cables obstructing the airflow in the system, or the ambient room
temperature being too warm. You should also check to make sure that the
chassis cover is installed and that all fans are present and operating normally.
Finally, check the air seals for damage. The air seals are located under the
blower fan and beneath the frame cross section that separates the drive bay area
from the serverboard area of the chassis.
!
NIC2: Indicates network activity on GLAN2 when flashing .
!
NIC1: Indicates network activity on GLAN1 when flashing.
!
HDD: Indicates SCSI/IDE channel activity. On the SuperServer 6113L-8/
6113L-i this light indicates SCSI/IDE and/or CD-ROM drive activity when flashing.
NIC2
NIC1
