Chapter 5: Advanced Serverboard Setup

5-25

5-11 SCSI and IDE Disk Drive Connections

When connecting the hard disk drive cables, please note that a red mark on a

wire typically designates the location of pin 1.

SCSI Activity LED
(6113L-8 only)

The SCSI Activity LED is located

next to the LSI SCSI controller.

When the SCSI Activity LED blinks,

it indicates that one or both of the

SCSI channels are active.

IDE Connectors

There are no jumpers to con-

figure the onboard IDE#1 and

#2 connectors. See the table

below for pin definitions.

Pin Number

Function

1

Reset IDE

3

Host Data 7

5

Host Data 6

7

Host Data 5

9

Host Data 4

11

Host Data 3

13

Host Data 2

15

Host Data 1

17

Host Data 0

19

GND

21

DRQ3

23

I/O Write-

25

I/O Read-

27

IOCHRDY

29

DACK3-

31

IRQ14

33

Addr 1

35

Addr 0

37

Chip Select 0

39

Activity

Pin Number

Function

2

GND

4

Host Data 8

6

Host Data 9

8

Host Data 10

10

Host Data 11

12

Host Data 12

14

Host Data 13

16

Host Data 14

18

Host Data 15

20

Key

22

GND

24

GND

26

GND

28

BALE

30

GND

32

IOCS16-

34

GND

36

Addr 2

38

Chip Select 1-

40

GND

IDE Connector Pin Definitions

(J37, J35)
