Chapter 6: Advanced Chassis Setup
6-5
Accessing the Drive Bays
SCSI/IDE Drives: Because of their hotswap capability, you do not need to access
the inside of the chassis or power down the system to install or replace SCSI
drives. Proceed to the next step for instructions. (For installing/removing IDE
drives, you do not need to access the inside of the system but you will need to
remove power from the system first.)
CD-ROM Drive: For installing/removing a CD-ROM drive, you will need to gain
access to the inside of the 6113L-8/6113L-i by removing the top cover of the
chassis. Proceed to the "CD-ROM Drive Installation" section later in this chapter
for instructions.
Note: Only a "slim" CD-ROM drive will fit into the 6113L-8/6113L-i.
Figure 6-3. Removing the Front Bezel
1. Unlock
2. Press release knob
3. Remove bezel assembly
