-6-
N(/(*(/Fg\e
@EKI
F;L:
K@FE
:fem\pfi=\\[
Type .................................................................................... Direct Current Variable Speed
Horsepower ........................................................................................................
1 ⁄
10
HP
Voltage .............................................................................................................220VDC
Phase ................................................................................................................ Single
Amps ..................................................................................................................... 1A
Number of Speeds ............................................................................................... Variable
Speed ........................................................................................................... 10–34 RPM
Cycle ................................................................................................................. 60 Hz
Power Transfer ...................................................................................................Gearbox
Bearings ......................................................................................... Sealed and Lubricated
DX`eJg\Z`]`ZXk`fej
Fg\iXk`fe@e]fidXk`fe
Number of Sanding Drums ............................................................................................. 1
Maximum Board Width ............................................................................................... 18"
Minimum Board Width ................................................................................................. 2"
Maximum Board Thickness ............................................................................................ 6"
Minimum Board Thickness ...........................................................................................
1 ⁄
4
"
Minimum Board Length ................................................................................................ 6"
Sanding Drum Speed .......................................................................................... 1850 FPM
Sanding Drum Diameter ............................................................................................... 4"
Conveyor Feed Rate ...........................................................................................5–17 FPM
Sandpaper Length ..................................................................................................... 48"
Sandpaper Width ...................................................................................................... 19"
JXe[`e^;ild@e]fidXk`fe
Drum Type ......................................................................................................... Rubber
Drum Diameter ......................................................................................................... 4"
:fejkilZk`fe@e]fidXk`fe
Conveyor Belt ...................................................................................... Heavy-Duty Rubber
Body ...................................................................................................................Steel
Paint ......................................................................................................... Powder Coat
Table and Column .............................................................................................. Cast Iron
Cabinet Stand ........................................................................................................Steel
Fk_\i@e]fidXk`fe
Number of Pressure Rollers ............................................................................................ 2
Pressure Roller Type ................................................................................................Steel
Pressure Roller Diameter .............................................................................................
3 ⁄
4
"
Number of Dust Ports ................................................................................................... 1
Dust Port Size ........................................................................................................... 4"
Fk_\iJg\Z`]`ZXk`fej1
Country of Origin ....................................................................................................... Taiwan
Warranty .................................................................................................................. 2 Year
Serial Number Location ................................................................................... ID Label on Front
Assembly Time ...........................................................................................................1 Hour
Required Air Pressure ................................................................................................... 57 PSI
=\Xkli\j1
Variable Speed Conveyor Feed
Pneumatic Belt Tracking
Emergency Brake System
Spring Belt Tensioning System
Amp Load Meter
