-10-
N(/(*(/Fg\e
:
K
I
@:
8
C
;FEFKnfibfepfli\c\Zki`ZXcjpjk\d
`] pfl Xi\ lejli\ XYflk \c\Zki`ZXc
Zf[\jXe[n`i`e^J\\bXjj`jkXeZ\]ifd
X hlXc`]`\[ \c\Zki`Z`Xe% @^efi`e^ k_`j
nXie`e^ZXeZXlj\\c\ZkifZlk`fe#]`i\#
fidXZ_`e\[XdX^\%
))'MFg\iXk`fe
The Model W1813 is wired for 220V single-phase opera-
tion. We recommend connecting this machine to a dedi-
cated circuit with a verified ground, using the circuit size
given below. Never replace a circuit breaker with one of
higher amperage without consulting a qualified electri-
cian to ensure compliance with wiring codes. This ma-
chine must be connected to a grounded circuit!
A plug is not supplied with this machine. See below for
the recommended plug type for this machine.
If you are unsure about the wiring codes in your area or
you plan to connect your machine to a shared circuit, you
may create a fire or circuit overload hazard—consult a
qualified electrician to reduce this risk.
We do not recommend using an extension cord; however,
if you have no alternative, use the following guidelines:
• Use a cord rated for Standard Service (S).
• Do not use an extension cord longer than 50 feet.
• Ensure that the cord has a ground wire and pin.
• Use the gauge size listed below as a minimum.
Fg\iXk`e^MfckX^\ 8dg;iXn D`e%:`iZl`kJ`q\ I\Zfdd\e[\[Gcl^
220V Operation 15 Amps 20A NEMA 6-20 (not incl.) 12 Gauge
=`^li\+% NEMA 6-20 plug and receptacle.
-$)'G -$)'I
K_\ dXZ_`e\ dljk Y\ gifg\icp j\k lg Y\]fi\ `k `j
jX]\kffg\iXk\%;FEFKZfee\Zkk_`jdXZ_`e\kfk_\
gfn\i jfliZ\ lek`c `ejkilZk\[ kf [f jf `e k_\ K\jk
Ilegfik`fef]k_`jdXelXc%
