Woodstock SHOPFOX W1813 - Manual (Page 6)

-4-
N(/(*(/Fg\e
@EKI
F;L:
K@FE
:fekifcj
=`^li\)% Sanding cabinet controls. =`^li\*% Control panel identification.
8% Upper Roller
9% Left Oscillation Disc
:% Oscillation Control Valve
;% Sanding Belt Tension Lock Lever
<% Sanding Belt Tension Lever
=% Sanding Drum
>% Sanding Belt 19" x 48" ?% Amperage Load Chart
@% Amperage Load Meter
A% Power Light
B% Sanding Motor ON Button
C% Emergency Stop Button
D% Conveyor Feed Rate Dial
E% Conveyor ON/OFF Switch w/Disabling Key
