-14-
N(/(*(/Fg\e
J<
K
L
G
-% Lift and move the sander assembly into position over
the cabinet stand so that the mounting holes line up
(see
=`^li\j0Æ(').
.% Secure the sander assembly to the cabinet stand
with the four M8-1.25 x 25 hex bolts and 8mm flat
washers.
/% Open the sanding belt access door on the left side
of the machine, and remove the red shipping brace
securing the sanding drum to the conveyor assembly
(see
=`^li\(().
=`^li\0% Sander assembly mounting points
on left side.
Only use a forklift rated for at least 750 lbs. that is in
good working condition. Use assistants to steady the
load when lifting and moving the sander assembly. If
the sander assembly should tip or fall, serious per-
sonal injury and property damage could result.
=`^li\('% Sander assembly mounting
points on right side.
=`^li\((% Shipping brace.
Shipping Brace
