-15-
N(/(*(/Fg\e
J<
K
L
G
:fdgi\jj\[8`i
A steady supply of clean, dry air of 57–60 PSI (not to
exceed 120 PSI) is required for the operation of the
sanding belt oscillation system and pneumatic motor
brake. Without the correct supply of compressed air, the
machine will not start.
KfZfee\ZkXe[Zfe]`^li\Zfdgi\jj\[X`i]fik_\jXe[$
\i#[fk_\j\jk\gj1
(% Connect the source of compressed air to the air
regulator inlet valve on the back of the machine (see
=`^li\()).
)% Lift up on the air regulator adjusting knob and turn
it so that the air pressure dial reads 57–60 PSI, then
push the adjusting knob down to lock the setting.
To avoid possible personal injury from
exploding compressed air components
or damage to the sander, never exceed
120 PSI of incoming compressed air to
the mill's regulator.
=`^li\()% Air regulator assembly on the
back of the sander.
Adjusting
Knob
Air Pressure
Dial
Air Inlet
Valve
;F EFK fg\iXk\ k_`j dXZ_`e\ n`k_flk Xe X[\hlXk\
[ljkZfcc\Zk`fejpjk\d%K_`jdXZ_`e\Zi\Xk\jjlYjkXe$
k`XcXdflekjf]nff[[ljkn_`c\fg\iXk`e^%=X`cli\kf
lj\ X [ljk Zfcc\Zk`fe jpjk\d ZXe i\jlck `e j_fik Xe[
cfe^$k\idi\jg`iXkfip`cce\jj%
Recommended CFM at Dust Port: ...................400 CFM
Do not confuse this CFM recommendation with the rating
of the dust collector. To determine the CFM at the dust
port, you must take into account many variables, includ-
ing the CFM rating of the dust collector, the length of
hose between the dust collector and the machine, the
amount of branches or Y's, and the amount of other open
lines throughout the system. Explaining this calculation
is beyond the scope of this manual. If you are unsure of
your system, consult an expert or purchase a good dust
collection "how-to" book.
KfZfee\Zkk_\[ljkZfcc\Zk`fe_fj\#[fk_\j\jk\gj1
(% Fit a 4" dust hose over the dust port on top of the
machine, as shown in =`^li\(*, and secure it in
place with a hose clamp.
)% Tug the hose to make sure it does not come off. A
tight fit is necessary for proper performance.
;ljk:fcc\Zk`fe
=`^li\(*% Dust hose connected to dust
port.
