Dx`egxikjc`jk, G8 i k j – Woodstock SHOPFOX W1813 User Manual
Page 51
-49-
N(/(*(/Fg\e
G8
I
K
J
DX`eGXikjC`jk
REF PART #
DESCRIPTION
REF PART #
DESCRIPTION
194
X1813194
CONNECTING TUBE
228
X1813228
SPECIAL SCREW
195
X1813195
4-WAY VALVE
229
X1813229
SPACER
196
X1813196
AIR INLET 1/4 NPT
230
XP608
BALL BEARING 608ZZ
197
X1813197
CONNECTOR
231
XPW01M
FLAT WASHER 8MM
198
X1813198
AIR PRESSURE SAFETY SWITCH
232
X1813232
BRACKET
199
X1813199
AIR PRESSURE BRAKE SOLENOID
233
XPS06M
PHLP HD SCR M5-.8 X 20
200
XPS10
PHLP HD SCR 10-24 x 1-1/2
234
X1813234
GEAR WASHER 5MM
201
XPLN04
LOCK NUT 10-24
235
X1813235
OSCILLATION CYLINDER
202
X1813202
AIR PLUG
236
X1813236
PIPE JOINT
203
X1813203
PNEUMATIC MUFFLER
237
X1813237
SANDING BELT
204
X1813204
SUPPORT ARM
238
X1813238
LEVER
205
XPW01M
FLAT WASHER 8MM
239
X1813239
KNOB
206
X1813206
ELEVATION ROD GUIDE
240
X1813240
SANDING BELT GUARD
207
XPLW02
LOCK WASHER 1/4
241
X1813241
DEPTH OF CUT SAFETY PLATE
208
XPSB01
CAP SCREW 1/4-20 X 5/8
242
X1813242
PRESSURE ROLLER
209
X1813209
COMPRESSION SPRING
243
X1813243
PRESSURE ROLLER BUSHING
210
XP51106
THRUST BEARING 51106
244
X1813244
PRESSURE ROLLER BRACKET R.
211
X1813211
LOCK COLLAR
245
X1813245
PRESSURE ROLLER BRACKET L.
212
X1813212
SANDING BELT ELEVATION ROD
246
X1813246
ROLLER SUPPORT BRACKET L.
213
X1813213
CRANK LEFT
247
X1813247
ROLLER SUPPORT BRACKET R.
214
X1813214
CRANK RIGHT
248
XPS76M
PHLP HD SCR M8-1.25 X 12
215
XPSS50
SET SCREW 1/4-20 X 2
249
X1813249
COMPRESSION SPRING
216
XPW06
FLAT WASHER 1/4
250
X1813250
SIDE COVER LOCK KNOB
217
X1813217
OSCILLATION VALVE
251
X1813251
SIDE COVER
218
X1813218
COMPRESSION SPRING
252
X1813252
HINGE PIN
219
XPSB21M
CAP SCREW M4-.7 X 30
253
XPB07M
HEX BOLT M8-1.25 X 25
220
X1813220
PIPE JOINT
254
X1813254
CABINET
221
X1813221
UPPER ROLLER SUPPORT FRAME
256
X1813256
DOOR
222
X1813222
UPPER ROLLER BRACKET
257
X1813257
DOOR LOCK
223
X1813223
UPPER ROLLER
258
X1813258
CONTACTOR NHD C-090 220V
224
X1813224
UPPER ROLLER SHAFT
259
X1813259
OL RELAY NHD NTH-17 14-17A
225
X1813225
OSCILLATION SENSOR PLATE
260
X1813260
STAND FOOT
226
X1813226
SUPPORT BRACKET
261
XPN08
HEX NUT 3/8-16
227
X1813227
SUPPORT PLATE
262
XPW04M
FLAT WASHER 10MM
