RECORD SET
3
English
83
11
Turn the jog dial to set the sensitivity
(OFF or 1 through 10), and then turn the
shuttle dial clockwise.
The cursor moves to “MODE”.
[Settings] ( indicates default setting)
12
Turn the shuttle dial clockwise.
“A” flashes for the “MODE”.
13
Turn the jog dial to select a “MODE”,
and then turn the shuttle dial clockwise.
The mode selection is confirmed and the cursor returns to
the top left position.
[Settings] ( indicates default setting)
14
Set “LEVEL” and “MODE” for T-2
through T-4 using the same procedure
(i.e., steps 8 through 13).
z
Motion sensor positions are common for T-1 through
T-4, and different settings cannot be made.
z
Sensitivity levels and modes can be set individually for
T-1 through T-4.
15
Turn the shuttle dial counter-clockwise.
Motion sensor settings are confirmed and the
To stop motion sensor recording
(1) During recording, display the SET> screen and turn the shuttle dial clockwise. (2) The motion sensor screen is displayed. Turn the sensitivity level OFF. Setting Description OFF Motion sensing is not carried out. 1 to10 Motion sensing is carried out. Lower values A CH01 T-2 LEVEL : 1 MODE : A A CH01 T-2 LEVEL : 1 MODE : A Setting Description A The motion sensor alarm is triggered when a B The motion sensor alarm is triggered when a A AND B The motion sensor alarm is triggered when a A AND NB By setting A to important points (or suspected A TO B The motion sensor alarm is triggered when an B TO A The motion sensor alarm is triggered when an C A motion sensor alarm is triggered when the e00_l8hbg_us_7.book Page 83 Thursday, November 25, 2004 1:44 PM
correspond to higher sensitivities.
moving object is detected in A.
moving object is detected in B.
moving object is detected by a sensor in both A
and B.
points of motion) and setting B to non-moving
points, motion can be detected at point A even
when the overall brightness changes and in other
situations where motion at both A and B would
normally be detected.
object is detected moving from A to B. (within 2
seconds from A to B)
object is detected moving from B to A. (within 2
seconds from B to A)
entire image changes uniformly. In this way,
sprays and other similar measures can be
protected against. (Setting of sensor positions is
unnecessary.)
