INITIAL SET
2
English
55
Use the following procedure to set a unique title for each
camera so that these titles can be displayed on-screen.
Titles can be up to 10 characters in length per camera.
The following characters can be used.
z
Letters: A to Z
z
Numbers: 0 to 9
z
Symbols: - : . / * _ (space)
Example: Setting the title “HALL-1F” for Camera No. 3.
1
Press the [MENU] button.
The MENU indicator lights up and the is
displayed.
2
Turn the jog dial to select “1. INITIAL
SET”, and then turn the shuttle dial
clockwise.
The screen is displayed.
3
Turn the jog dial to select “3. TITLE
SET”, and then turn the shuttle dial
clockwise.
The normal monitoring screen is displayed with a title
setting field in the center.
4
Press the No. 3 [CAMERA SELECT]
button.
The video from Camera No. 3 is displayed on-screen.
5
Turn the shuttle dial clockwise.
The first position for title setting flashes.
6
Turn the jog dial to select “H”.
Characters change in the following sequence as the jog
dial is turned.
7
Turn the shuttle dial clockwise.
The character selection is confirmed and the cursor moves
one position to the right.
z
When changing a character, move the cursor to that
character by turning the shuttle dial clockwise or
counter-clockwise, and then enter the required
character.
8
Repeat steps 5 and 6 to enter the
remaining characters.
9
When you have finished making
settings, press the [EXIT/OSD] button.
The setting procedure is ended and the display returns to
the normal screen.
The default setting is “-----01” (camera No.).
Setting camera titles
MENU
1.LAUNGUAGE/CLOCK SET ->
2.CAMERA DETECT ->
3.TITLE SET ->
4.HOLIDAY SET ->
5.TIME PERIOD SET ->
MOVE:JOG SELECT:SHUTTLE
