SCREEN SET 5
English
103
3
Turn the jog dial to move the cursor to
“MAIN/MON.2 MONITOR SET”, and then
turn the shuttle dial clockwise.
The
4
Turn the shuttle dial clockwise.
“T-1” starts to flash for “TIME PERIOD”.
5
Turn the jog dial to select T-1, T-2, T-3,
or T-4 for the time period, and then turn
the shuttle dial clockwise.
After setting the period, the cursor moves to “ON” for the
“MAIN MON.”.
6
Turn the jog dial clockwise or counter-
clockwise to move the cursor to the
main-monitor or monitor 2 channel to be
changed.
On the DSR-3709, select cameras No. 1 through No. 9.
7
Turn the shuttle dial clockwise.
“ON” flashes.
8
Turn the jog dial to select “ON” or “OFF”,
and then turn the shuttle dial clockwise.
After confirming this setting, the cursor moves one position
to the right.
[Settings] (‹ indicates default setting)
9
Use the same procedure to set the
remaining channels.
10
Press the [EXIT/OSD] button.
The setting procedure is ended and the display returns to
the normal screen.
z When setting a number of time periods together, use
the jog dial to move the cursor to the next period after
completing step 9, and repeat the process from step 4.
z The time period for “T-1” through “T-4” changes to that
of “TIME PERIOD A” or “TIME PERIOD B” on P.57.
1.MULTI SCREEN : CHANGE
QUAD POSITION SET ->
MULTI 9 POSITION SET ->
MULTI 16 POSITION SET ->
2.SEQUENCE SET : 1S
SEQUENCE SET ->
MAIN/MON.2 MONITOR SET ->
3.MASK : OFF
MASK SET ->
4.COLOR LEVEL SET ->
TIME PERIOD : T-1 (06:00-11:30)
CH 01 02 03 04 05 06 07 08
MAIN MON. ON ON ON ON ON ON ON ON
MON.2 ON ON ON ON ON ON ON ON
CH 09 10 11 12 13 14 15 16
MAIN MON. ON ON ON ON ON ON ON ON
MON.2 ON ON ON ON ON ON ON ON
TIME PERIOD : T-1 (06:00-11:30)
CH 01 02 03 04 05 06 07 08
MAIN MON. ON ON ON ON ON ON ON ON
MON.2 ON ON ON ON ON ON ON ON
CH 09 10 11 12 13 14 15 16
MAIN MON. ON ON ON ON ON ON ON ON
MON.2 ON ON ON ON ON ON ON ON
TIME PERIOD : T-1 (06:00-11:30)
CH 01 02 03 04 05 06 07 08
MAIN MON. ON ON ON ON ON ON ON ON
MON.2 ON ON ON ON ON ON ON ON
CH 09 10 11 12 13 14 15 16
MAIN MON. ON ON ON ON ON ON ON ON
MON.2 ON ON ON ON ON ON ON ON
Settings Description
‹ ON Camera images displayed.
OFF Camera images not displayed.
TIME PERIOD : T-1 (06:00-11:30)
CH 01 02 03 04 05 06 07 08
MAIN MON. ON ON ON ON ON ON ON ON
MON.2 ON ON ON ON ON ON ON ON
CH 09 10 11 12 13 14 15 16
MAIN MON. ON ON ON ON ON ON ON ON
MON.2 ON ON ON ON ON ON ON ON
TIME PERIOD : T-1 (06:00-11:30)
CH 01 02 03 04 05 06 07 08
MAIN MON. ON ON ON OFF ON ON ON ON
MON.2 ON ON ON ON ON ON ON ON
CH 09 10 11 12 13 14 15 16
MAIN MON. ON ON ON ON ON ON ON ON
MON.2 ON ON ON ON ON ON ON ON
EXIT/OSD
