SCREEN SET 5
102
English
SE
TTIN
GS
Use the following procedure to scroll through video from all
cameras using a specified period.
A switching time for automatic selection can only be set for
full screen and quad display.
Example:
Automatic switching of a full screen on the monitor
every 5 seconds.
1
Press the [MENU] button and turn the
jog dial to select “4. SCREEN SET”, and
then turn the shuttle dial clockwise.
The screen is displayed. The cursor
moves to “1. MULTI SCREEN”.
2
Turn the jog dial to move the cursor to
“2. SEQUENCE SET”, and then turn the
shuttle dial clockwise.
“1S” flashes.
3
Turn the jog dial to set change the
period to “5S”, and then turn the shuttle
dial clockwise.
Automatic selection is set to a period of 5 seconds.
4
Press the [EXIT/OSD] button.
The setting procedure is ended and the display returns to
the normal screen.
z Switching interval is set for all cameras from main
monitor and monitor 2.
z The interval can be set between 1 and 30 seconds.
z Select “INDIV.” in step 2 to set automatic selection time
for each display screen, monitor, or camera.
(1) Select “INDIV.” in step 2 and turn the shuttle dial
clockwise
The cursor moves to “SEQUENCE SET”.
(2) Turn the shuttle dial clockwise
The screen is displayed.
(3) Set items with the jog dial and turn the shuttle dial
clockwise to select
Select “INDIV.” to set automatic selection time for
each camera.
Example:
Specifying a monitor to display each camera’s video at
the set period (as indicated by TIME PERIOD A and
TIME PERIOD B).
1
Make timer settings for “TIME PERIOD
A” and “TIME PERIOD B” from PERIOD SET>. (JP.57)
Specify “TIME PERIOD A” and “TIME PERIOD B”.
2
Press the [MENU] button and turn the
jog dial to select “4. SCREEN SET”, and
then turn the shuttle dial clockwise.
The screen is displayed. The cursor
moves to “1. MULTI SCREEN”.
Setting the period and monitors for
automatic screen selection
Setting the automatic selection period
MENU
1.MULTI SCREEN : CHANGE
QUAD POSITION SET ->
MULTI 9 POSITION SET ->
MULTI 16 POSITION SET ->
2.SEQUENCE SET : 1S
SEQUENCE SET ->
MAIN/MON.2 MONITOR SET ->
3.MASK : OFF
MASK SET ->
4.COLOR LEVEL SET ->
1.MULTI SCREEN : CHANGE
QUAD POSITION SET ->
MULTI 9 POSITION SET ->
MULTI 16 POSITION SET ->
2.SEQUENCE SET : 5S
SEQUENCE SET ->
MAIN/MON.2 MONITOR SET ->
3.MASK : OFF
MASK SET ->
4.COLOR LEVEL SET ->
Setting the main monitor and monitor 2
EXIT/OSD
MAIN MON. FULL : 1S
QUAD : 1S
MON.2 FULL : 1S
INDIVIDUAL INTERVAL (SEC)
01: 1S 02: 1S 03: 1S 04: 1S
05: 1S 06: 1S 07: 1S 08: 1S
09: 1S 10: 1S 11: 1S 12: 1S
13: 1S 14: 1S 15: 1S 16: 1S
MENU
