Chapter 4 Architecture Details

4.1

Top Level Functional Architecture

Functionally, the transceiver can be divided into the following sections:

„

100Base-TX transmit and receive

„

10Base-T transmit and receive

„

MII or RMII interface to the controller

„

Auto-negotiation to automatically determine the best speed and duplex possible

„

Management Control to read status registers and write control registers

4.2

100Base-TX Transmit

The data path of the 100Base-TX is shown in

Figure 4.1

. Each major block is explained below.

4.2.1

100M Transmit Data Across the MII/RMII Interface

For MII, the MAC controller drives the transmit data onto the TXD bus and asserts TXEN to indicate
valid data. The data is latched by the transceiver’s MII block on the rising edge of TXCLK. The data
is in the form of 4-bit wide 25MHz data.

For RMII, the MAC controller drives the transmit data onto the TXD bus and asserts TXEN to indicate
valid data. The data is latched by the transceiver’s RMII block on the rising edge of REF_CLK. The
data is in the form of 2-bit wide 50MHz data.

Figure 4.1 100Base-TX Data Path

M A C

T x

D river

M LT -3

C onverter

N R Z I

C onverter

4B /5B

E ncoder

C A T-5

R J45

25M H z by

5 bits

N R Z I

M LT-3

M LT -3

M LT -3

S cram bler

and P IS O

M II/R M II

25M H z

by 4 bits

E xt R ef_C LK (for R M II only)

P LL

M II 25 M hz by 4 bits

or

R M II 50 M hz by 2 bits

M LT -3

M agnetics

125 M bps S erial

T X _C LK

(for M II only)
