TXD2

24

I8

Transmit Data 2: The MAC transmits data to the transceiver using this
signal in MII Mode.

„

This signal should be grounded in RMII Mode.

TXD3

25

I8

Transmit Data 3: The MAC transmits data to the transceiver using this
signal in MII Mode.

„

This signal should be grounded in RMII Mode.

nINT/

TXER/

TXD4

18

IOPU

nINT – Active low interrupt output. Place an external resistor pull-up to
VDDIO.

„

See

Section 4.10

for information on how nINTSEL is used to determine

the function for this pin.

TXERMII Transmit Error: When driven high, the 4B/5B encode process
substitutes the Transmit Error code-group (/H/) for the encoded data word.
This input is ignored in 10Base-T operation.

TXD4MII Transmit Data 4: In Symbol Interface (5B Decoding) mode, this
signal becomes the MII Transmit Data 4 line, the MSB of the 5-bit symbol
code-group.

„

TXD4 is not used in RMII Mode.

„

This signal is mux’d with nINT

TXEN

21

IPD

Transmit Enable: Indicates that valid data is presented on the TXD[3:0]
signals, for transmission. In RMII Mode, only TXD[1:0] have valid data.

TXCLK

20

O8

Transmit Clock: Used to latch data from the MAC into the transceiver.

„

MII (100BT): 25MHz

„

MII (10BT): 2.5MHz

„

This signal is not used in RMII Mode.

RXD0/

MODE0

11

IOPU

RXD0Receive Data 0: Bit 0 of the 4 data bits that are sent by the
transceiver in the receive path.

MODE0PHY Operating Mode Bit 0: set the default MODE of the PHY.

„

See

Section 5.3.9.2

for information on the MODE options.

RXD1/

MODE1

10

IOPU

RXD1Receive Data 1: Bit 1 of the 4 data bits that are sent by the PHY
in the receive path.

MODE1PHY Operating Mode Bit 1: set the default MODE of the PHY.

„

See

Section 5.3.9.2

for information on the MODE options.

RXD2/

RMIISEL

9

IOPD

RXD2Receive Data 2: Bit 2 of the 4 data bits that are sent by the
transceiver in the receive path.

„

The RXD2 signal is not used in RMII Mode.

RMIISEL – MII/RMII Mode Selection: Latched on the rising edge of the
internal reset (nRESET) based on the following strapping:

„

By default, MII mode is selected.

„

Pull this pin high to VDDIO with an external resistor to select RMII mode,

RXD3/

PHYAD2

8

IOPD

RXD3Receive Data 3: Bit 3 of the 4 data bits that are sent by the
transceiver in the receive path.

„

This signal is not used in RMII Mode.

„

This signal is mux’d with PHYAD2

PHYAD2PHY Address Bit 2: set the SMI address of the transceiver.

„

See

Section 5.3.9.1

for information on the ADDRESS options.

Table 3.2 MII/RMII Signals (continued) 32-QFN (continued)

SIGNAL

NAME

32-QFN

PIN #

TYPE

DESCRIPTION
