-4-
Model W1823 (Mfg. Since 9/10)
IN
TR
O
DU
CT
IO
N
Phone #: (360) 734-3482 • Online Tech Support: [email protected] • Web: www.shopfox.biz
B68=>C:
HE:8>;>86I>DCH
Dfkfi
Type ..........................................................................................TEFC Capacitor Start Induction
Class .....................................................................................................................Class "E"
Horsepower .............................................................................................................. 1 1 ⁄
2
HP
Voltage ...............................................................................................................110V/220V
Phase ....................................................................................................................... Single
Amps ..................................................................................................................... 15/7.5A
Speed .................................................................................................................. 3450 RPM
Cycle ........................................................................................................................ 60 Hz
Number Of Speeds ............................................................................................................. 1
Pre-Wired ..................................................................................................................110V
Power Transfer .................................................................................................... Direct Drive
Bearings ............................................................................................... Sealed and Lubricated
DX`eJg\Z`]`ZXk`fej
Fg\iXk`fe
Air Suction Capacity ............................................................................................806 CFM
Maximum Static Pressure (Inches of Water) .................................................................... 10.4
Main Inlet Size .......................................................................................................... 6"
4" x 6" Y-Adapter Included ........................................................................................... Yes
Y-Adapter Main Port Size .............................................................................................. 6"
Number of Y-Adapter Inlets ............................................................................................ 2
Y-Adapter Inlet Size .................................................................................................... 4"
Machine Material Collection Capacity .................................................................... 4.3 cu. ft.
Canister Filter Capacity ............................................................................... 0.2–2.0 Microns
9X^@e]fidXk`fe
Number of Lower Bags ................................................................................................. 2
Capacity ......................................................................................................1.13 cu. ft.
Diameter x Length ....................................................................................14 5 ⁄
8
"D x 11 7 ⁄
8
"L
:Xe`jk\i=`ck\i
Number of Canister Filters ............................................................................................ 1
Diameter x Length ....................................................................................14 1 ⁄
2
"D x 23 5 ⁄
8
"L
Collection Drum Size ........................................................................................ 20 gallons
@dg\cc\i@e]fidXk`fe
Type .............................................................................................................Radial Fin
Diameter .............................................................................................................12 3 ⁄
4
"
Blade Thickness ........................................................................................................ 1 ⁄
8
"
Fm\iXcc;`d\ej`fej
Weight .................................................................................................................. 140 lbs.
Length x Width x Height ..............................................................................37"L x 32"W x 70 1 ⁄
2
"H
Foot Print (Length x Width) ..................................................................................... 37"L x 32"W
BD9:AL&-'(
EDGI67A:8N8ADC:
Df[\cN(/)*DXZ_`e\Jg\Z`]`ZXk`fej#GX^\(f])
